Introduction
  • Cerebral Palsy General
  • Definitions
    • many gait disorders described in cerebral palsy
    • no universally accepted classification system
    • strict definitions have been unsuccessful at classifying up to 40% of CP gait patterns.
  • Epidemiology
    • gait disorder are the primary reason for orthopaedic consultations in CP patients
      • independent gait expected between 12 to 18 months old in non-CP children
  • Pathophysiology
    • can be broken into
      • primary deviations
        • those caused by the primary CNS insult including
          • spasticity
          • weakness
          • compromised proprioceptive pathways
        • treatment
          • best treated by pharmacological or neurosurgical pathways
      • secondary deviations
        • growth-related deviations that arise due to abnormal loading in the setting of primary gait deviations including
          • anatomic shortening of muscle-tendon units (myotatic contractures)
          • persistent bony deformities, i.e. femoral anteversion
          • joint subluxations/dislocations, i.e. hip subluxation or equinoplanovalgus feet
        • treatment
          • treated with primarily orthopaedic surgery
      • tertiatry deviations
        • compensations related to secondary gait deviations
        • treatment
          • address primary or secondary deviations
Classification
  • Plane of deformity
    • breaks into
      • sagittal plane conditions
      • transverse plan conditions
    • breaking down gait into planes of deformity allows the practicioner to better plan multiple-level interventions when they are indicated
  • Eponym (Sagittal Plane Patterns)
    • useful for simplification purposes and helpful to describe overall pattern even given high variability of segmental deviations in each pattern
      • Equinus gait
        • definition
          • term "equinus" may be used to refer to the foot position relative to the tibia, an achilles contracture, or a toe-walking pattern with a one-level deviation (e.g. no knee/hip involvement)
          • absence of heal strike during gait is the most common meaning of the term when referring to CP patients
          • isolated equinus gait is common in hemiplegics
        • equinus may be a
          • true equinus
            • defined by the foot position in relationship to the tibia being less than plantigrade
          • apparent equinus
            • defined by a foot position that is normal in relationship to the tibia, however heel strike does not occur due to multilevel changes (flexion of the knee most common)
      • Jump gait
        • deformity includes hip flexion, knee flexion, and equinus ankle spastic deformity (may be apparent ankle equinus)
        • multi-level gait deviations where treatment of underlying spasticity should be considered
      • Crouch gait
        • a combination of hip flexion, knee flexion, and flatfoot or calcaneal contact pattern
        • common in diplegic CP
        • pathophysiology
          • may be an iatrogenic consequence of lengthening the achilles in a jump gait pattern if the other levels of gait deviations are not addressed proprely
        • Levels of deviation
          • Calcaneal contact pattern throughout stance phase
          • Increased knee flexion throughout stance phase due to disruption of the ankle plantar flexion-knee extension couple
        • compensated crouch gait
          • refers to tertiary deviations that allow the knee extensor mechanism to be off-loaded during stance phase (e.g. pelvic or truncal forward tilt) - this may be well-tolerated by younger children with CP and low body mass
        • uncompensated crouch gait
          • occurs when there is persistent overloading of the extensor mechanism, and this will occur for all children with CP at some point
      • Stiff-knee gait
        • common in spastic diplegic CP
        • characterized by limited knee flexion in swing phase due to rectus femoris firing out of phase (seen on EMG)
        • note that all other named gaits are stance phase deviations
        • Evaluation
          • instrumented gait analysis shows quadriceps activity from terminal stance throughout swing phase
        • Complications
          • Stiff knee gait can be a compenstation due to deviations at the hip; surgical management will not help this subset of stiff-knee gait
  • Transverse Plane Deviations
    • Introduction
      • while the sagittal plane gait deviations are both named and referred to more commonly, the transverse plane should not be forgotten in a comprehensive gait analysis or surgical intervention
      • internal, external, and neutral progression angles may occur at the hip, knee, and foot
        • kinematic analysis will assist in detection of segmental progression angle deviations
    • Evaluation
      • physical exam for torsional deformities
      • these are commonly due to secondary deviations as torsional forces are placed on the long bones due to underlying spastic tone
    • Management
      • Secondary deviations may be corrected at time of SEMLS surgery
Evaluation
  • Gait analysis
    • has helped identify distinct problems and guide orthopaedic treatment
      • quantitative gait analysis is more accurate at detecting gait abnormalities than is qualitative assessment alone
    • gait analysis includes comprehensive examination with
      • physical exam findings
        • contractures and torsional abnormalities
        • Silfverskiöld test distinguishes between contracture of gastrocnemius only versus combined gastrocnemius and soleus
      • kinetic analysis
        • linear and angular motion analysis
      • kinematic analysis
        • description of movement including time-dependent variable (velocity, etc.)
      • pedobarography
        • special force plate that shows contact pressures through the stance phase
      • dynamic electromyography
        • muscle activation detected at different (normal or abnormal) start points in gait
Treatment
  • Non-operative Management
    • Bracing
      • ankle foot orthosis
        • flexible deformities - ankle is passively correctable to neutral while maintaining a subtalar neutral position
        • posterior leaf-spring orthoses used in presence of excessive ankle plantar flexion in the swing phase
    • chemodenervation (botulinum neurotoxin A)
      • common indications for ambulatory patients
        • hamstring spasticity without fixed deformity (jump gait)
      • may be useful to combine with AFOs, either in isolation or before/after surgical intervention
  • Surgical Treatments
    • Single-event, multi-level surgery (SEMLS)
      • indications
        • SEMLS approach has become the gold-standard of CP gait surgery
      • goals
        • addressing all primary (spasticity) and secondary (i.e. contractures) at a single surgery is essential to avoiding iatrogenic worsening of gait
      • requires a comprehensive gait analysis (see above)
      • often, these patients have foot breakdown (planovalgus and hallux valgus) that may need to be corrected concurrently if the goal is to achieve a heel-toe gait pattern
      • AFOs and aggressive physical therapy for re-training and strengthening following releases is an essential component of SEMLS intervention
    • Sagittal Plane Deviations
      • Ankle Equinus
        • tendo-achilles lengthening
          • indications
            • rigid deformities - ankle is not passively correctable to neutral
            • true equinus
          • CAUTION - isolated heel cord lengthening in the presence of tight hamstrings and hip flexors will lead to progressive flexion at the hips and knees, possibly worsening a crouched gait
          • techniques
            • gastrocnemius recessionSilfverskiöld test positive
              • intra-operative goal is to obtain 10 degrees of dorsiflexion with the knee extended
            • achilles lengthening
              • multiple hemi-lengthenings or a Z-lengthing can be performed - Silfverskiöld negative;
            • when possible, a gastrocnemius recession limits the risk of iatrogenic over-lengthening
      • Knee Flexion Contractures (static and dynamic)
        • medial hamstring lengthening
          • for mild knee dysfunction, usually younger patients with less than 5 degrees knee flexion deformity
          • Fractional lengthening at the myotendinous junction is ideal
          • Hamstring contractures often recur, especially in jump gait
        • transfer of the semitendinosus combined with growth plate surgery
          • for severe flexed knee gait, combined with knee flexion deformities of 10-25 degrees in the patients with at least two years of growth remaining
        • osteotomy with tendon advancement or shortening
          • supracondylar extension osteotomy +/- patellar tendon advancement or shortening
          • for knee flexion deformities of 10-30 degrees, with severe quadriceps lag close to or already at skeletal maturity
      • Stiff-knee Gait
        • Rectus Transfer to create knee flexion vector with rectus activation
      • Transverse Plane Deviations
        • Treatment
          • operative interventions should be part of SEMLS surgeries whenever possible
        • femoral anteversion / Hip internal rotation deviation
          • external rotation proximal femur osteotomy
        • external tibial torsion
          • Supramalleolar osteotomy
        • Complications
        • correcting a planovalgus foot (e.g. lateral column lengthening, talonavicular fusion) may obviate the need for tibial rotational correction
        • Examination underanesthesia after each segmental correction is important
Techniques
  • Gastrocnemius recession
    • Horizontal or Verticle incision at the level of the myotendinous junction of the gastroc
    • Identify and protect the sural nerve (superficial to fascia)
    • Sharply devide the tendon only, preserving the muscle fibers not yet joined to the tendon
    • Incise all deeper bands that prevent release of contracture (small raphes may be present in the tendon
    • Manipulate the ankle
    • goal of treatment is 10 degrees of dorsiflexion
Complications

  • multiple simultaneous soft tissue releases without careful gait analysis
    • elongated patellar tendon (patellar alta) is another complication of this condition that is difficult to treat
    • tendo-achilles lengthening may worsen knee pathology if careful gait analysis isn't performed
