Monteggia Fracture - Pediatric - Pediatrics

summary
- Monteggia Fractures in the pediatric population are defined as proximal ulna fractures or plastic deformation of the ulna with an associated radial head dislocation.
- Diagnosis can be made with plain radiographs of the elbow.
- Treatment may be closed reduction and casting for length stable ulna fractures with a stable radiocapitellar joint. Surgical management is indicated for radial heads that are not stable following closed reduction.

Epidemiology
- Demographics
  - 4 to 10 years of age is peak incidence

Etiology
- Definition
  - radial head dislocation plus
  - proximal ulna fracture or
  - plastic deformation of the ulna without obvious fracture

                        Classification

                        Bado Classification

                        Type I

                        Apex anterior proximal ulna fracture with anterior dislocation of the radial head

                        Type II

                        Apex posterior proximal ulna fracture with posterior dislocation of the radial head

                        Type III

                        Apex lateral proximal ulna fracture with lateral dislocation of the radial head

                        Type IV

                        Fractures of both the radius and ulna at the same level with ananterior dislocation of the radial head (1-11% of cases)

Presentation
- Symptoms
  - pain, swelling, and deformity about the forearm and elbow
- Physical exam
  - must palpate over radial head with all ulna fractures because spontaneous relocation of radial head is common
  - must examine for plastic deformation of the ulna if there is a presumed isolated radial head dislocation

    isolated radial head dislocations almost never occur in pediatric patients

Imaging
- Radiographs
  - obtain elbow radiographs for all forearm fractures to evaluate for radial head dislocation

    assess radiocapitellar line on every lateral radiograph of the elbow

    a line down the radial shaft should pass through the center of the capitellar ossification center
  - obtain forearm radiographs for all radial head dislocations

Treatment
- Nonoperative
  - closed reduction of ulna and radial head dislocation and long arm casting

    indications

    Bado Types I-III with

    radial head is stable following reduction

    length stable ulnar fracture pattern

    reduction technique

    reduction technique uses traction

    radial head will reduce spontaneously with reduction of the ulna and restoration of ulnar length

    for Type I, elbow flexion is the main reduction maneuver

    if reduction of radiocapitellar joint is unsuccessful, annular ligament is most common block to reduction

    immobilization

    Type I 110° of flexion and full supination to tighten interosseous membrane and relax biceps tendon

    Type II fulll extension.

    Type III full extension and valgus mold
- Operative
  - pinning/nailing of ulna + reduction of radial head ± annular ligament repair/reconstruction

    indications

    Bado Types I-III with

    radial head is not stable following reduction

    ulnar length is not stable (unable to maintain ulnar length)

    acute Bado Type IV

    open fractures

    older patients ≥ 10y if closed reduction is not stable

    symptomatic individuals (pain, loss of forearm motion, progressive valgus deformity) who had delayed treatment or missed diagnosis

    technique

    open reduction of radial head through a lateral approach if needed in chronic (>2-3 weeks old) Monteggia fractures where radial head still retains concave structure

    annular ligament reconstruction almost never required for acute fractures
  - ORIF similar to adult treatment

    indications

    closed physes
