Lisfranc Injury (Tarsometatarsal fracture-dislocation)

Author:
Topic updated on 03/31/14 9:00am
Introduction
  • A conditions characterized by disruption between the articulation of the medial cuneiform and base of the second metatarsal
    • unifying factor is disruption of the TMT joint complex
    • injuries can range from mild sprains to severe dislocations
    • may take form of purely ligamentous injuries or fracture-dislocations
    • ligamentous vs. bony injury pattern has treatment implications
  • Epidemiology
    • incidence
      • account for 0.2% of all fractures
    • demographics
      • more common in the third decade
      • more common in males
  • Mechanism & Pathoanatomy
    • causes include MVAs, falls from height, and athletic injuries
    • mechanism is usually caused by indirect rotational forces and axial load through hyperplantar flexed forefoot
      • hyperflexion/compression/abduction moment exerted on forefoot and transmitted to the TMT articulation
      • metatarsals displaced in dorsal/lateral direction
  • Associated conditions
    • proximal metatarsal fractures or tarsal fractures
      • Lisfranc equivalent injuries can present in the form of continguous proximal metatarsal fractures or tarsal fractures
  • Prognosis
    • missed injuries can result in progressive foot deformity, chronic pain and dysfunction
      • tarsometatarsal fracture-dislocations are easily missed and diagnosis is critical
Anatomy
  • Osteology
    • Lisfranc joint complex consists of three articulations including
      • tarsometatarsal articulation
      • intermetatarsal articulation
      • intertarsal articulations
  • Ligaments
    • Lisfranc ligament
      • critical to stabilizing the second metatarsal and maintenance of the midfoot arch
      • An interosseous ligament that goes from medial cuneiform to base of 2nd metatarsal on plantar surface
      • Lisfranc ligament tightens with pronation and abduction of forefoot
    • plantar tarsometatarsal ligaments
      • injury of the plantar ligament between the medial cuneiform and the second and third metatarsals along with the Lisfranc ligament is necessary to give transverse instability.
    • dorsal tarsometatarsal ligaments
      • dorsal ligaments are weaker and therefore bony displacement with injury is often dorsal
    • intermetatarsal ligaments
      • between second-fifth metatarsal bases
      • no direct ligamentous attachment between first and second metatarsal
  • Biomechanics
    • Lisfranc joint complex is inherently stable with little motion due to
      • stable osseous architecture
        • second metatarsal fits in mortise created by medial cuneiform and recessed middle cuneiform, "keystone configuration"
      • ligamentous restraints
        • see individual ligaments above
  • Columns of the midfoot
    • medial column
      • includes first tarsometatarsal joint
    • middle column
      • includes second and third tarsometatarsal joints
    • lateral column
      • includes fourth and fifth tarsometatarsal joints (most mobile)
Classification
  • Multiple classification schemes described
    • none proven useful for determining treatment and prognosis
Physical Exam
  • Symptoms
    • severe pain
    • inability to bear weight
  • Physical exam
    • inspection & palpation
      • medial plantar bruising
      • swelling throughout midfoot
      • tenderness over tarsometatarsal joint
    • motion & stability
      • instability test
        • grasp metatarsal heads and apply dorsal force to forefoot while other hand palpates the TMT joints
          • dorsal subluxation suggests instability
          • if first and second metatarsals can be displaced medially and laterally, global instability is present and surgery is required
        • when plantar ligaments are intact, dorsal subluxation does not occur with stress exam and injury may be treated nonoperatively
    • provocative tests
      • may reproduce pain with pronation and abduction of forefoot
    • compartment syndrome
      • always check for compartment syndrome and take compartment pressures if high suspicion
Imaging
  • Radiographs
    • recommended views
      • AP, lateral, obliques
      • stress radiograph
        • may be helpful to show instability when non-weight bearing radiographs are normal and there is high suspicion
      • weight-bearing radiographs with comparison view
        • may be necessary to confirm diagnosis
    • findings
      • five critical radiographic signs that indicate presence of midfoot instability
        1. disruption of the continuity of a line drawn from the medial base of the second metatarsal to the medial side of the middle cuneiform
        2. widening of the interval between the first and second ray
        3. medial side of the base of the fourth metatarsal does not line up with medial side of cuboid on oblique view
        4. metatarsal base dorsal subluxation on lateral view
        5. disruption of the medial column line (line tangential to the medial aspect of the navicular and the medial cuneiform)
      • lateral
        • non weight-bearing radiographs may show dorsal displacement of the proximal base of the first or second metatarsal
      • AP
        • malalignment of medial margin of the second metatarsal base and the medial edge of the middle cuneiform diagnostic of Lisfranc injury
        • may see bony fragment (fleck sign) in first intermetatarsal space
          • represents avulsion of Lisfranc ligament from base of 2nd metatarsal
          • diagnostic of Lisfranc injury
      • oblique
        • malalignment of fourth metatarsal and cuboid
  • CT scan
    • useful for diagnosis and preoperative planning
  • MRI
    • can be used to confirm presence of purely ligamentous injury
Treatment
  • Nonoperative
    • cast immobilization for 8 weeks
      • indications
        • no displacement on weight-bearing and stress radiographs and no evidence of bony injury on CT (usually dorsal sprains)
        • certain nonoperative candidates
          • nonambulatory patients
          • presence of serious vascular disease
          • severe peripheral neuropathy
          • instability in only the transverse plane
  • Operative
    • open reduction and rigid internal fixation
      • indications
        • any evidence of instability (> 2mm shift)
        • favored in bony fracture dislocations as opposed to purely ligamentous injuries
      • outcomes
        • anatomic reduction required for a good result
    • primary arthrodesis of the first, second and third tarsometatarsal joints
      • indications
        • purely ligamentous arch injuries
      • outcomes
        • level 1 evidence demonstrates equivalent functional outcomes and decreased rate of hardware removal or revision surgery compared to primary ORIF
        • primary arthodesis is an alternative to ORIF in patients with any evidence of instability with possible benefits
        • medial column tarsometatarsal fusion shown to be superior to combined medial and lateral column tarsometatarsal arthrodesis
    • midfoot arthrodesis
      • indications
        • destabilization of the midfoot's architecture with progressive arch collapse and forefoot abduction
        • chronic Lisfranc injuries that have led to advanced midfoot arthrosis and have failed conservative therapy
Technique
  • General Surgical Considerations
    • equipment
      • fluoroscopy and radiolucent table
      • small fragment and mini fragment sets (2.0mm-4.0mm screws)
      • reduction clamps, k-wires, dental pick, Homan retractors
      • small battery powered drill
    • timing of surgery
      • emergently only if
        • the presence of compartment syndrome
        • open injury
        • irreducible dislocations
      • delay operative treatment until soft tissue swelling subsides (up to 2-3 weeks)
      • if grossly unstable and in presence of significant soft tissue swelling consider early external fixation
  • Open reduction and rigid internal fixation
    • approach
      • single or dual longitudinal incisions can be used based on injury pattern and surgeon preference
      • longitudinal incision made in the web space between first and second rays
      • first TMT joint is exposed between the long and short hallux-extensor tendons
    • reduction & fixation
      • reduce intercuneiform instability first
      • fix first through third TMT joints with transarticular screws
        • screw fixation is more stable than K-wire fixation
    • postoperative care
      • early midfoot ROM, protected weight bearing, and hardware removal (k-wires in 6-8 weeks, screws in 3-6 months
      • gradually advance to full weight bearing at 8-10 weeks
      • if patient is asymptomatic and screws transfix only first through third TMT joints, they may be left in place
      • preclude return to vigorous athletic activities for 9 to 12 months
  • Primary arthrodesis of the first, second and third tarsometatarsal joints
    • arthrodesis & fixation
      • expose TMT joints and denude all joint surfaces of cartilage
      • use cortical screws to fuse joints
    • postoperative care
      • apply cast or splint for 6 weeks
      • progress weight bearing between 6 and 12 weeks in removable boot
      • full weight bearing in standard shoes by 12 weeks post-op
  • Midfoot arthrodesis
    • arthrodesis & fixation
      • expose TMT joints and midfoot  and remove cartilage from first, second, and third TMT joints
      • add bone graft
      • reduce the deformity using windlass mechanism
      • variety of definitive fixation constructs exist
    • postoperative care
      • touch down weight bearing in a cast for 6 weeks
      • begin weight bearing at 10 weeks if evidence of healing is noted on radiographs
Complications
  • Posttraumatic arthritis
    • most common complication
    • may cause altered gait and long term disability
    • treat advanced midfoot arthrosis with midfoot arthrodesis
  • Nonunion
    • uncommon
    • revision surgery indicated unless patient is elderly and low demand



Please Rate Educational Value!
4.0
Average 4.0 of 27 Ratings

Qbank (11 Questions)

TAG
(OBQ13.32) A 35-year-old motorcyclist is involved in a motor vehicle accident. He complains of pain and swelling in his right foot. Examination demonstrates dorso-medial midfoot tenderness. A clinical photograph is seen in Figure A. Supine and standing radiographs are seen in Figures B and C respectively. What is the most appropriate definitive treatment step? Topic Review Topic
FIGURES: A   B   C

1. Non-weightbearing in a CAM walker boot for 6-10 weeks
2. Weightbearing as tolerated in a CAM walker boot for 6-10 weeks
3. Closed reduction and K-wire fixation of the first and second tarsometatarsal joints
4. Open reduction and rigid internal fixation of the first and second tarsometatarsal joints
5. Open reduction and rigid internal fixation of the first to third tarsometatarsal joints and K-wire fixation of the fourth and fifth tarsometatarsal joints

PREFERRED RESPONSE ▶
TAG
(OBQ12.13) A 25-year-old male sustains a left foot injury while playing soccer. His radiographs are shown in figures A and B. Which of the following techniques would lead to the best outcome when addressing his injury? Topic Review Topic
FIGURES: A   B

1. Rigid cast immobilization
2. Spanning medial column external fixation
3. Percutaneous screw fixation of medial column of foot
4. K-wire fixation of medial column of foot
5. Open reduction and internal fixation of medial column of foot

PREFERRED RESPONSE ▶
TAG
(OBQ11.185) A 40-year-old male sustains a right foot injury after a head-on motor vehicle collision. He is unable to place weight on the foot to ambulate, and pain is exacerbated with abduction of the midfoot. He is neurovascularly intact in the foot. An injury radiograph is shown in Figure A, while a clinical image of the foot is shown in Figure B. What is the most appropriate next step in management? Topic Review Topic
FIGURES: A   B

1. Open reduction and arthrodesis of the medial two tarsometatarsal joints
2. External fixation of the foot followed with staged open reduction and screw fixation across the medial two tarsometatarsal joints
3. Open reduction and screw fixation across the medial three tarsometatarsal joints and percutaneous pinning of the 4th and 5th tarsometatarsal joints
4. Debridement of Morel-Lavallee lesion and external fixation of the foot followed with staged open reduction and screw fixation across the medial two tarsometatarsal joints
5. Open reduction and screw fixation across the medial two tarsometatarsal joints with anatomic ligamentous reconstruction

PREFERRED RESPONSE ▶
TAG
(OBQ09.244) A 24-year-old man sustains an injury to his left foot. Stress radiographs are seen in Figure A. Injury to which ligament or ligaments are needed to produce the transverse instability seen here? Topic Review Topic
FIGURES: A

1. Spring ligament and bifurcate ligament
2. Interosseous first cuneiform-second metatarsal ligament
3. Interosseous first cuneiform-second metatarsal ligament and plantar ligament between the first cuneiform and the second and third metatarsals
4. Bifurcate ligament and Interosseous first cuneiform-second metatarsal ligament
5. Long plantar ligament and plantar ligament between the first cuneiform and the second and third metatarsals

PREFERRED RESPONSE ▶
TAG
(OBQ08.139) As an alternative to open reduction and internal fixation for the injury pattern seen in Figure A, what alternative treatment has been shown to be more effective? Topic Review Topic
FIGURES: A   B

1. open reduction and primary arthrodesis of the medial and middle column
2. open reduction and primary arthrodesis of the medial, middle, and lateral column
3. closed percutanous pinning
4. closed reduction and casting
5. partial weight bearing in removable boot

PREFERRED RESPONSE ▶
TAG
(OBQ08.222) Which ligament connects the medial cuneiform to the base of the second metatarsal? Topic Review Topic

1. Spring ligament
2. Chopart ligament
3. Lisfranc ligament
4. Intermetatarsal ligament
5. Calcaneofibular ligament

PREFERRED RESPONSE ▶
TAG
(OBQ07.103) A 37-year-old man was involved in a high velocity motor vehicle accident 6 months ago. He spent 4 months in the ICU recovering from a severe head injury. He has now transitioned to a rehabilitation hospital and complains of left foot pain that becomes severe with weightbearing and attempted ambulation. Radiographs are provided in figures A-C. Which of the following is the best management? Topic Review Topic
FIGURES: A   B   C

1. Custom orthotics and physical therapy
2. Closed reduction and percutaneous screw fixation of 1st through 3rd tarsometatarsal joints
3. Open reduction internal fixation of 1st through 3rd tarsometatarsal joints
4. Arthrodesis of 1st through 3rd tarsometatarsal joints
5. Tarsometatarsal arthrodesis and triple arthrodesis

PREFERRED RESPONSE ▶
TAG
(OBQ06.100) A 30-year-old equestrian caught her foot in a stirrup 1 week ago and now complains of midfoot pain with difficulty bearing weight. Radiographs are shown in figure A. What treatment is most appropriate? Topic Review Topic
FIGURES: A

1. non-weight bearing in an aircast
2. weight bearing as tolerated in a walking cast
3. modified-Brostrom procedure
4. delayed corrective osteotomy and arthrodesis of the medial column
5. operative reduction of the tarsometatarsal complex

PREFERRED RESPONSE ▶
TAG
(OBQ06.132) A 54-year-old male sustained a right foot injury two years ago in a motor vehicle collision. The patient reports he was treated for a ligament injury in his foot with a non-weightbearing short leg cast for 2 months. Physical examination reveals no signs of infection and full sensation and motor strength in the foot. During gait examination he has pain during push-off of the right foot and loss of medial longitudinal arch height in the stance phase. A radiograph obtained at the time of initial injury is shown in Figure A. What is the most appropriate next step in management? Topic Review Topic
FIGURES: A

1. Lateral column lengthening procedure (Evans)
2. Tarsometatarsal joint arthrodesis
3. Talonavicular joint arthrodesis
4. Lateral wedge closing calcaneal osteotomy (Dwyer)
5. Subtalar, talonavicular, and calcaneocuboid joint arthrodesis (Triple)

PREFERRED RESPONSE ▶
TAG
(OBQ04.1) A 54-year-old woman sustains a twisting injury to her foot. A radiograph is provided in Figure A. Which of the following is the most appropriate treatment? Topic Review Topic
FIGURES: A

1. closed reduction and pinning
2. closed reduction and casting
3. open reduction and internal fixation
4. CAM walker and weight bearing as tolerated
5. weight bearing as tolerated

PREFERRED RESPONSE ▶
Sorry, this question is available to Virtual Curriculum members only.

Click HERE to learn more and purchase the Virtual Curriculum today!





Cases

http://upload.orthobullets.com/cases/1764/1- 20.4.10.jpg http://upload.orthobullets.com/cases/1764/3 - 20.4.10.jpg http://upload.orthobullets.com/cases/1764/4 - 28.5.10.jpg
HPI - trauma at work in April 2010, initially only treated for scaphoid fracture with...
poll What would be your treatment for this injury ?
1/27/2014
144 responses
4
http://upload.orthobullets.com/cases/1541/10001.jpg http://upload.orthobullets.com/cases/1541/10002.jpg http://upload.orthobullets.com/cases/1541/10003.jpg
HPI - passenger TA overriding injury, Lt foot lateral lay
poll What is your choice of treatment this patient?
6/24/2013
235 responses
3
http://upload.orthobullets.com/cases/1530/preop left.jpg http://upload.orthobullets.com/cases/1530/denis lisfr 1.jpg http://upload.orthobullets.com/cases/1530/lis.jpg
HPI - twisting injury left foot while playing basketball
poll closed reduction or reduction with fixation
6/8/2013
312 responses
4
http://upload.orthobullets.com/cases/1525/115076545.jpg http://upload.orthobullets.com/cases/1525/115076548.jpg http://upload.orthobullets.com/cases/1525/115076550.jpg
HPI - The patient fell down stairs 4 days ago and she injured her left leg.
poll What kind of treatment do you prefer?
6/5/2013
1089 responses
4
See More Cases

Videos

video
This video shows a educational presentation reviewing the evaluation and treatme...
3/4/2013
627 views
5
video
So how did a gynaecologist get a foot injury named after him. And what on earth...
3/4/2013
2152 views
4
video
This video demonstrates the mechanism of a Lisfranc injury in various profession...
3/4/2013
1547 views
1
video
Educational video describing the classifications of lisfranc fractures. Become a...
3/4/2013
177 views
0
See More Videos

Posts

post
Marin-Pena OR, Viloria Recio F, Sanz Gómez T, Larrainzar Garijo R
Injury. 2012 Dec;43 Suppl 2:S79-82. PMID: 23622999 (Link to Pubmed)
5/19/2014
34 responses
2
post
Kuo RS, Tejwani NC, Digiovanni CW, Holt SK, Benirschke SK, Hansen ST, Sangeorzan BJ
J Bone Joint Surg Am. 2000 Nov;82-A(11):1609-18. PMID: 11097452 (Link to Pubmed)
2/20/2014
20 responses
0
post
Henning JA, Jones CB, Sietsema DL, Bohay DR, Anderson JG
Foot Ankle Int. 2009 Oct;30(10):913-22. PMID: 19796583 (Link to Pubmed)
6/9/2013
132 responses
4
post
Kuo RS, Tejwani NC, Digiovanni CW, Holt SK, Benirschke SK, Hansen ST, Sangeorzan BJ
J Bone Joint Surg Am. 2000 Nov;82-A(11):1609-18. PMID: 11097452 (Link to Pubmed)
3/21/2013
62 responses
5
See More Posts

Groups


Evidence & References Show References




Topic Comments
