Pediatric Spondylolysis & Spondylolisthesis - Spine

Summary
- Pediatric Spondylolysis & Spondylolisthesis represent a continuum of disease where there is a fracture of the pars interarticularis (spondylolysis) which may progress to anterior subluxation of one vertebral body anterior to the adjacent inferior vertebral body (spondylolisthesis).
- Diagnosis of spondylolysis alone can be challenging on imaging and the ideal study is controversial. Radiographs, CT scan, and MRI may all play a role. Spondylolisthesis is diagnosed on a lateral radiograph.
- Treatment may be nonoperative or surgical depending on the degree of back pain, malalignment of vertebral bodies, and neurological symptoms.

Epidemiology
- Incidence
  - common

    up to 6-7% of adolescent athletes

    implicated in up to 47% of low back pain complaints in this population
- Demographics
  - higher incidence in Native Americans
- Anatomic location
  - typically involves pars of L5 and anterolisthesis of L5 relative to S1
- Risk factors
  - prevalence of spondylolysis may be as high as 47% in certain athletes (gymnasts, weightlifters, football linemen)
  - contact sports and those involving repetitive hyperextension (ex. linebacker)
  - higher sacral table index, pelvic incidence, sacral slope, and lower sacral table angle

Etiology
- Pathophysiology
  - conditions represent a continuum of disease including

    pars stress reaction

    defined as sclerosis of pars without complete bone disruption

    spondylolysis

    defined as a complete fracture of the pars interarticularis

    mechanism

    defects are not present at birth and develop over time (seen in 4-6% if population)

    usually activity related and occurs from repetitive hyperextension

    isthmic spondylolisthesis (spondylolytic spondylolithesis)

    defined as forward translation of one vertebral segment over the one beneath it due to a pars defect

    risks of progression

    approximately 15% of individuals with a pars interarticularis lesion have progression to spondylolisthesis

    the larger the slip the more likely it is to progress

    > Myerding 2 (>50% slip)

    dysplastic slips (Wiltse Type I) are more likely to progress

    severity of current slip

    correlates most strongly with pelvic incidence

    spondyloptosis

    100% translation of one vertebra over the next caudal vertebra
- Genetics
  - possible autosomal dominant inheritance pattern

                        Classification

                        Wiltse-Newman Classification

                        Type I

                        Dysplastic

                        Secondary to congenital abnormalities of lumbosacral articulation including mal-oriented or hypoplastic facets, sacral deficiency, poorly developed pars

                        Posterior elements are intact (no spondylolysis)

                        More significant neurologic symptoms

                        Type II-A

                        Isthmic - Pars Fatigue Fx

                        Type II-B

                        Isthmic - Pars Elongation due to healed stress fx

                        Type II-C

                        Isthmic - Pars Acute Fx

                        Type III

                        Degenerative

                        Type IV

                        Traumatic

                        Type V

                        Neoplastic

                        Marchetti-BartolozziClassification

                        Developmental

                        Includes Wiltse I and II

                        Acquired

                        Traumatic, postsurgical, pathologic, degenerative

                        Meyerding Classification

                        Grade I

                        < 25%

                        Grade II

                        25-50%

                        Grade III

                        50-75%

                        Grade IV

                        75-100%

                        Grade V

                        Spondyloptosis

Presentation
- History
  - classic history is healthy active adolescent who presents with acute onset of low back pain with athletic activity
- Symptoms
  - asymptomatic

    many cases of spondylolysis are asymptomatic
  - low back pain

    no association between radiologic grade and clinical presentation

    symptoms include insidious onset of activity related low back pain
  - leg symptoms

    buttock pain

    hamstring tightness (most common) and knee contracture

    radicular pain (L5 nerve root)
  - listhetic crisis

    severe back pain aggravated by extension and relieved by rest

    neurologic deficit

    hamstring spasm
  - bowel and bladder symptoms

    rare
  - cauda equina syndrome (rare)
- Physical exam
  - inspection

    high grade/dysplastic patients may develop "heart shaped buttocks" due to sacral prominence

    flattened lumbar lordosis

    palpation

    palpable step off of spinous process
  - motion

    limitation of lumbar flexion and extension

    measure popliteal angle to evaluate for hamstring tightness
  - neurovascular

    straight leg raise may be positive

    rectal exam if bowel and bladder symptoms present
  - provocative tests

    pain with single-limb standing lumbar extension
  - gait

    may walk with a crouched gait when symptoms severe

Imaging
- Pars stress reaction & spondylolysis
  - radiographs

    indications

    AP and lateral indicated in all patients with concern for spondylolysis and spondylolithesis

    AP view

    may see sclerosis of the stress reaction

    lateral view

    may show defect in pars in 80%

    oblique view

    views may show sclerosis and elongation in pars interarticularis (scotty dog sign)

    some studies have shown that oblique does not provide more diagnostic information than AP and lateral radiographs but does increase radiation exposure
  - CT

    inidcations

    best study to delineate anatomy of lesion

    findings

    pars stress reaction will show up as sclerosis on x-rays and CT scan
  - single photon emission computer tomography (SPECT)

    indications

    previously considered the best diagnostic adjunct when plain radiographs are negative; however, now rarely performed given unnecessary radiation exposure

    can also detect osteoid osteomas, sacroiliitis, osteitis pubis, and disc herniation

    techniques

    combines technique of bone scan with CT in order to help localize an area of abnormal activity seen on bone scan
  - MRI

    indications

    negative ragdiographs with high suspicion

    very acute presentation

    any neurological deficits

    sensitivity & specificity

    recent studies have shown MRI to be as sensitive and specific as SPECT, with the additional benefit of avoiding radiation exposure
  - bone scan

    indications

    excellent screening tool for low back pain in children or adolescents

    sensitivity & specificity

    most sensitive (however lesion may be cold)
- Spondylolisthesis
  - radiographs

    views

    lateral x-ray used to measure slip angle and grade.

    flexion and extension radiographs used to evaluate instability

    measurements

    slip grade

    slippage on plain lateral radiographic imaging measured in accordance to the vertebra below

    the caudal vertebra is divided into four parts

    Grade I means a translation of the cranial vertebra of up to 25%

    Grade II of up to 50%

    Grade III of up to 75%

    Grade IV up to 100%

    Grade V describes the ptosis of the cranial vertebra

    slip angles

    methodology to determine slip angle

    most important determinant for nonunion and pain

    angle >45-50 degrees associated with greater slip progression, instability, and development of post-op pseudo

    pelvic incidence

    pelvic incidence = pelvic tilt + sacral slope

    a line is drawn from the center of the S1 endplate to the center of the femoral head

    a second line is drawn perpendicular to a line drawn along the S1 endplate, intersecting the point in the center of the S1 endplate

    the angle between these two lines is the pelvic incidence (see angle X in figure above)

    correlates with severity of disease

    pelvic incidence has direct correlation with the Meyerding–Newman grade

    pelvic tilt

    pelvic tilt = pelvic incidence - sacral slope

    a line is drawn from the center of the S1 endplate to the center of the femoral head

    a second vertical line (parallel with side margin of radiograph) line is drawn intersecting the center of the femoral head

    the angle between these two lines is the pelvic tilt (see angle Z in figure above)

    sacral slope

    sacral slope = pelvic incidence - pelvic tilt

    a line is drawn parallel to the S1 endplate

    a second horizontal line (parallel to the inferior margin of the radiograph) is drawn

    the angle between these two lines is the sacral slope (see angle Y in the figure above)
  - CT

    best study to diagnose and delineate anatomy of pars defect
  - MRI

    indicated if neurologic symptoms present

    useful to diagnose associated central and foraminal stenosis

Treatment
- Nonoperative
  - observation alone (no activity limitations)

    indications

    asymptomatic patients

    regardless of slip grade which does not correlate with clinical presentation

    return to in contact sports is controvesial

    limited evidence to guide surgeons following surgical management, decision must be individualized

    some data shows patients who stop sports for at least 3 months have improved outcomes compared to those who continue to play

    outcomes

    typically do well and remain asymptomatic
  - physical therapy & activity restriction

    indications

    symptomatic isthmic spondylolysis

    symptomatic low-grade spondylolisthesis

    technique

    physical therapy should be done for 6 months and include

    hamstring stretching

    pelvic tilts

    abdominal strengthening

    outcomes

    most improve and do not require surgery

    watch low grade dysplastic carefully as there is a higher chance of progression
  - bracing for 6 to 12 weeks

    indications

    acute pars stress reaction spondylolysis

    isthmic spondylolysis that has failed to improve with physical therapy

    low grade spondylolisthesis that has failed to improve with physical therapy

    technique

    typically a TLSO

    outcomes

    brace immobilization is superior to activity restriction alone for acute stress reaction spondylolysis
- Operative
  - pars interarticularis repair

    indications

    L1 to L4 isthmic defect that has failed nonoperative management

    multiple pars defects

    outcomes

    typically superior to fusion procedures, preserves motion
  - L5-S1 posterolateral fusion, +/- ALIF, +/- sacroiliac fusion

    indications

    L5 spondylolysis that has failed nonoperative treatment

    low grade spondylolisthesis (Myerding Grade I and II) that

    has failed nonoperative treatment

    is progressive

    has neurologic deficits

    is dysplastic due to high propensity for progression

    return to sport

    some evidence to support that ALIF may help return to competetitive sports

    most surgeons allow return to noncontact sports 3-6 months following fusion and return to contact sports 6-12 months (controversial)

    outcomes

    patients typically do well and return to sport in 3-6 months
  - L4-S1 posterolateral fusion, +/- reduction, +/- sacroiliac fusion, +/- ALIF

    indications

    high grade spondylolytic spondlylisthesis (Meyerding Grade III, IV, V)

    reduction is extremely controversial with no accepted guidelines

    outcomes

    patients typically do well but may have greater motion limitations with multi-level fusion

    over-aggressive reduction techniques may result in neurologic impairments

Techniques
- Par interarticularis repair
  - approach

    posterior midline approach to lumbar spine
  - technique

    repair pars defect with screw fixation, tension wiring, or screw and sublaminar hook technique

    decompression indicated if clinical symptoms of stenosis

    contraindications

    disc degeneration (obtain MRI for sx planning)
- L5-S1 posterolateral fusion +/- ALIF
  - approach

    posterior midline approach to lumbar spine
  - technique

    decompression only indicated if clinical symptoms of stenosis or radiculopathy

    in-situ fusion with bone grafting / with or without instrumentation
  - postoperative

    usually postoperative immobilization in a TLSO
- L4-S1 posterolateral fusion, +/- reduction, +/- sacroiliac fusion, +/- ALIF
  - approach

    posterior midline approach to lumbar spine
  - technique

    reduction

    reduction may be done with instrumentation or positioning

    pros of reduction

    can restore sagittal alignment and reduce lumbosacral kyphosis

    cons

    risk of significant complications (8-30%) including

    L5 is the most common nerve root injury with reduction

    sexual dysfunction

    catastrophic neurologic injury

    fusion/decompression

    usually instrumented

    the addition of decompression and anterior-posterior (360 deg) fusion is associated with more in-hospital complications

    the use of interbody cages in this population has decreased significantly, while costs associated with treatment in general have increased over time

Complications
- Neurologic deficits
  - consider neuromonitoring during reduction, especially in a high-grade slip
  - L5 n. root injury is the most common neuro cx
- Pseudoarthrosis
- Slip Progression
- Hardware failure

Prognosis
- Most symptomatic patients can be successfully managed nonoperatively
- In patients who fail non-operative management, spinal fusion results in 90% success rates
- Return to sports is controversial

Action	Numeric Key	Letter Key	Function Key
Show Bullets		S	Enter (frontside only)
20%	1	N
40%	2	H
60%	3	F	Enter (backside only)
80%	4	E
100%	5	M
Toss	0	T

Wiltse-Newman Classification
Type I	Dysplastic Secondary to congenital abnormalities of lumbosacral articulation including mal-oriented or hypoplastic facets, sacral deficiency, poorly developed pars Posterior elements are intact (no spondylolysis) More significant neurologic symptoms
Type II-A	Isthmic - Pars Fatigue Fx
Type II-B	Isthmic - Pars Elongation due to healed stress fx
Type II-C	Isthmic - Pars Acute Fx
Type III	Degenerative
Type IV	Traumatic
Type V	Neoplastic

Marchetti-BartolozziClassification
Developmental	Includes Wiltse I and II
Acquired	Traumatic, postsurgical, pathologic, degenerative

Meyerding Classification
Grade I	< 25%
Grade II	25-50%
Grade III	50-75%
Grade IV	75-100%
Grade V	Spondyloptosis
